Vibration transducers

The transducers are piezo-electric accelerometers of compression type; each individually tuned, with built-in pre­amplifier, designed for vibration monitoring of industrial machinery. The electrical signal is isolated from the transducer housing. Enhanced electronics and improved ambient characteristics deliver excellent performance in a very large area of applications.

The transducers are designed to withstand the rigors of industrial environments. Stainless, acid-proof steel housings, case isolation, and hermetic sealing make them very robust.

NEED AN EX VERSION?

Transducers and connectors approved under the ATEX directive, for use in potentially explosive atmosphere.

Want to know more about Vibration transducers?

By clicking “Submit”, you agree that your message and personal details will be sent by email to relevant recipient(s) at SPM Instrument. You hereby also agree that SPM Instrument and its subsidiaries will have access to the information you have provided and that these data will be stored on our email server. The data will not be saved in any other way. We will not use this information to contact you about matters other than those specified in your request. We will not share your information with third parties.

Technical overview

Our vibration transducers come in a variety of sizes, configurations, and specifications to perfectly suit your needs. All transducers are internally isolated. The frequency range is specified for the transducer when permanently installed. The measuring results will be affected at higher frequencies when using a magnetic foot.

Vibration transducers with top entry


Connection alternatives:
TB = 2-pin connector MIL-C-5015
TD = 4-pin M12 connector

Part number
Ex
Mounting thread
Connection
Frequency range
Sensitivity
SLD121 - M6, M8, M10, UNF TB 2-1000 Hz 1.2 mV/m/s2
SLD122 - M6, M8, M10, UNF TB 2-5000 Hz 4 mV/m/s2
SLD144 - M8 tapped hole for mounting stud* TB, TD 2-10 000 Hz 10 mV/m/s2
SLD244 Ex M8 tapped hole for mounting stud* TB, TD 2-10 000 Hz 10 mV/m/s2

* The mounting studs are available with thread sizes M6, M8, M10, and UNF 1/4″.

Vibration transducers with side entry


Connection alternatives:
S = Side entry, 2-pin connector MIL-C-5015

Part number
Ex
Mounting thread
Connection
Frequency range
Sensitivity
SLD144 - M6, M8, UNF S 2-10 000 Hz 10 mV/m/s2
SLD244 Ex M8 S 2-10 000 Hz 10 mV/m/s2



Vibration transducers MEMS with top entry



Part number
Ex
Mounting thread
Connection
Frequency range
Sensitivity
SLD322B-M8 - M8 2-pin MIL 1-2000 Hz 4 mV/m/s2
SLD322B-UNF - UNF 1/4" 2-pin MIL 1-2000 Hz 4 mV/m/s2
SLD334B-M8 - M8 2-pin MIL 1-2000 Hz 10 mV/m/s2
SLD334B-UNF Ex UNF 1/4 " 2-pin MIL 1-2000 Hz 10 mV/m/s2



Vibration transducers MEMS with side entry



Part number
Ex
Mounting thread
Connection
Frequency range
Sensitivity
SLD334S-G - M3/Glue 2-pin MIL 1-2000 Hz 10 mV/m/s2



Installation materials

Connectors, cables, and service box

We offer a wide range of connectors in composite or stainless-steel material. Composite material provides benefits such as vibration dampening and weight reduction, while stainless steel can withstand mechanical forces and works both in high and low temperatures, etc.

For our connectors, there are different types of cables, and to further secure the installation, we supply uncovered, acid-proof stainless steel conduits. These are protective covers slipped onto the cable and fixed to the transducer at the connector. Stainless steel cable clips are available for holding the conduit. For the protection of cable joints from moisture and water, a stainless, acid-proof steel service box is available.

Contact your SPM representative to learn more and discuss your needs.
